INFORMACIÓN TÉCNICA
Conjunto del cuadro
Cuadro | Carbon Advanced Composite frame, Full Internal Cable Routing, Flat Mount Disc Brakes 12×142 | |
Horquilla | Carbon Advanced Composite fork, Full Internal Cable Routing, Flat Mount Disc Brakes 12×100 | |
Juego de dirección | Integrated Internal Routing, 3 positions, 3 different heights |
Transmisión
Cambio Trasero | Shimano 105 7000 11s | |
Desviador | Shimano 105 7000 11s | |
Manetas cambio | Shimano 105 7020 11s | |
Plato | Shimano 105 7000 11s 50/34T | |
Piñon | Shimano 105 7000 11-30t 11s |
Frenos
Conjunto de frenos | Shimano 105 7070 11s Hydraulic Disc |
Ruedas
Cubiertas | Vittoria Zafiro 700x25C | |
Bujes | Vision Team 35 Disc 12×100 / 12×142 | |
Llantas | Vision Team 35 Disc |
Componentes
Manillar | Megamo Fov Compact | |
Potencia | Integrated Internal Routing | |
Tija sillín | Megamo 27,2mm |
Nos reservamos el derecho a modificar la información de la web sin previo aviso, incluido las especificaciones, modelos, colores y materiales. |
GEOMETRÍA RAISE 20 (22)
XS | S | M | L | XL | ||
---|---|---|---|---|---|---|
A
|
T/T | 507 | 523 | 541 | 559 | 576 |
B
|
C/S | 405 | 405 | 405 | 405 | 405 |
C
|
S/T | 422 | 453 | 473 | 499 | 525 |
D
|
H/T | 103 | 116 | 135 | 156 | 176 |
E
|
REACH | 357 | 369 | 381 | 393 | 405 |
F
|
STACK | 505 | 522 | 541 | 560 | 580 |
G
|
BB HEIGHT | 270 | 270 | 270 | 270 | 270 |
H
|
FRONT ANGLE | 70,5º | 72º | 72º | 72º | 72º |
I
|
REAR ANGLE | 73,5º | 73,5º | 73,5º | 73,5º | 73,5º |
HANDLEBAR AND STEM INTEGRATED:
XS | S | M | L | XL | ||
---|---|---|---|---|---|---|
90/400 | – | – | – | |||
100/400 | – | – | – | |||
110/420 | – | – | – | |||
120/440 | – | – | – |
FIT GUIDE | |
X-SMALL |
158 – 168
|
SMALL |
165 – 172
|
MEDIUM |
170 – 182
|
LARGE |
182 – 190
|
X-LARGE |
188 – 210
|
