Descripción
INFORMACIÓN TÉCNICA
Conjunto del cuadro
Cuadro | Full Itegratted Battery, Alloy e-bike specific frame, 12×148 Boost, Wheel travel: 140 mm | |
Horquilla | Suntour XCR 34 E-Bike+, Travel 130mm, Boost 15×110, Mini-Fender Included | |
Amortiguador | Rock Shox Deluxe Select R 210×55 Debonair Tune | |
Juego de dirección | FSA Orbit 1,5 E ZS 1-1/8” 1,5” |
Transmisión
Cambio Trasero | Shimano Deore 5120 10s | |
Manetas cambio | Shimano Deore 4100 10s | |
Plato | FSA 36t | |
Piñon | Shimano Deore 4100 11-46t |
Frenos
Conjunto de frenos | Shimano hydraulic disc MT200, 180mm |
Ruedas
Cubiertas | Maxxis Ikon 29 x 2,2 | |
Bujes | Boost System 15×110 12×148, E-Bike+ | |
Llantas | 29 Ready 25 |
Componentes
Manillar | Alloy Butted 31,8×780 mm, Rise: 12 mm, Back Sweep: 6º | |
Potencia | 3D Forged Alloy, Ext.: 60-70-90 mm, Rise: ±7º | |
Tija sillín | Megamo 31,6mm | |
Sillín | Megamo Specific E-Bike+ Saddle |
Componentes eléctricos
Motor | Central Motor DP, 80Nm, 250W, Torque Sensor | |
Batería | Integrated LI-ION Battery, 504 Wh | |
Display | LCD Screen panel |
Nos reservamos el derecho a modificar la información de la web sin previo aviso, incluido las especificaciones, modelos, colores y materiales. |
GEOMETRÍA RIDON FS (22)
S | M | L | |
---|---|---|---|
SIZE | 16 | 17,5 | 20,5 |
T/T | 580 | 595 | 645 |
C/S | 475 | 475 | 475 |
S/T | 405 | 450 | 520 |
H/T | 140 | 140 | 165 |
REACH | 408 | 423 | 465 |
STACK | 632 | 632 | 655 |
FRONT ANGLE | 66 | 66 | 66 |
REAR ANGLE | 73,5º | 73,5º | 73,5º |
L/T | 210X50 | 210X50 | 210X50 |
REAR TRAVEL | 140 | 140 | 140 |
WB | 1210 | 1225 | 1276 |
