Descripción
INFORMACIÓN TÉCNICA
Conjunto del cuadro
 |
Cuadro | Carbon Advanced Composite frame, Full Internal Cable Routing, Flat Mount Disc Brakes 12×142 |
 |
Horquilla | Carbon Advanced Composite fork, Full Internal Cable Routing, Flat Mount Disc Brakes 12×100 |
 |
Juego de dirección | Integrated Internal Routing, 3 positions, 3 different heights |
Transmisión
 |
Cambio Trasero | Sram Force AXS 12s |
 |
Desviador | Sram Force AXS 12s |
 |
Manetas cambio | Sram Force AXS 12s |
 |
Plato | Sram Force AXS 12s 48-35 Powermeter |
 |
Piñon | Sram Force AXS 12s 10-33t |
Frenos
 |
Conjunto de frenos | Sram Force AXS 12s |
Ruedas
 |
Cubiertas | Vittoria Corsa Graphene 2.0 Skinwall |
 |
Bujes | DT Swiss ARC 1100 50 / Mavic Cosmic SLR 45 |
 |
Llantas | DT Swiss ARC 1100 50 / Mavic Cosmic SLR 45 |
Componentes
 |
Manillar | Megamo Fov Compact |
 |
Potencia | Integrated Internal Routing |
 |
Tija sillín | Megamo 27,2mm |
 |
Sillín | Selle San Marco Shortfit Dynamic Wide Manganese Carbon Fiber Reinforced 250 x 144mm |
| Nos reservamos el derecho a modificar la información de la web sin previo aviso, incluido las especificaciones, modelos, colores y materiales. |
GEOMETRÍA RAISE AXS 02 (22)
| XS | S | M | L | XL | ||
|---|---|---|---|---|---|---|
|
A
|
T/T | 507 | 523 | 541 | 559 | 576 |
|
B
|
C/S | 405 | 405 | 405 | 405 | 405 |
|
C
|
S/T | 422 | 453 | 473 | 499 | 525 |
|
D
|
H/T | 103 | 116 | 135 | 156 | 176 |
|
E
|
REACH | 357 | 369 | 381 | 393 | 405 |
|
F
|
STACK | 505 | 522 | 541 | 560 | 580 |
|
G
|
BB HEIGHT | 270 | 270 | 270 | 270 | 270 |
|
H
|
FRONT ANGLE | 70,5º | 72º | 72º | 72º | 72º |
|
I
|
REAR ANGLE | 73,5º | 73,5º | 73,5º | 73,5º | 73,5º |
HANDLEBAR AND STEM INTEGRATED:
| XS | S | M | L | XL | ||
|---|---|---|---|---|---|---|
| 90/400 |  |
|
– | – | – | |
| 100/400 | – | |
|
– | – | |
| 110/420 | – | – | |
|
– | |
| 120/440 | – | – | – | |
|
| FIT GUIDE | |
| X-SMALL |
158 – 168
|
| SMALL |
165 – 172
|
| MEDIUM |
170 – 182
|
| LARGE |
182 – 190
|
| X-LARGE |
188 – 210
|
