Descripción
INFORMACIÓN TÉCNICA
Conjunto del cuadro
 |
Cuadro | Crave Full Carbon FSC Technology Carbon Swingarm, EP8 Specific Boost 12×148, Wheel travel: 160 mm, Tire clearance 29 x 2.6 |
 |
Horquilla | Fox 38 Factory e-bike+, Kashima 29, 160mm, grip 2, 15QRx110, 44mm rake |
 |
Amortiguador | Fox FLOAT X, Factory Series, Kashima 2pos-adj, Trunnion, Evol LV, 205×65 |
 |
Juego de dirección | Integrated Full Internal Cable Routing |
Transmisión
 |
Cambio Trasero | Sram X01 AXS 12s |
 |
Manetas cambio | Sram X01 AXS 12s |
 |
Plato | Sram E-Bike 36t |
 |
Piñon | Sram X01 AXS 12s |
Frenos
 |
Conjunto de frenos | Shimano XT M8020 Hydraulic disc 4-Piston, 203mm |
Ruedas
 |
Cubiertas | Front: 29×2,6 Maxxis Minion DHF, Rear: 29×2,6 Maxxis Minion DHR II, Tubeless Ready, EXO Protection |
 |
Bujes | DT Swiss HXC 1200 Carbon e-bike SP 29 CL 30 12/148 SSRAM |
 |
Llantas | DT Swiss HXC 1200 Carbon e-bike SP 29 CL 30 12/148 SSRAM |
Componentes
 |
Manillar | Raceface Carbon ,SIXC 3/4 L RSR,785mm |
 |
Potencia | Raceface |
 |
Tija sillín | Fox Transfer Kashima 31,6mm telescopic seat post, remote adjustment |
 |
Sillín | Megamo Specific E-Bike+ Saddle |
Componentes eléctricos
 |
Motor | Shimano EP8 250W |
 |
Batería | Shimano Integrated LI-ION Battery, 630 Wh |
 |
Display | Shimano EP8 |
| Nos reservamos el derecho a modificar la información de la web sin previo aviso, incluido las especificaciones, modelos, colores y materiales. |
GEOMETRÍA CRAVE CRB ALL-MTN (22)
| S | M | L | |||
|---|---|---|---|---|---|
|
A
|
T/T | 588 | 615 | 650 | |
|
B
|
C/S | 455 | 455 | 455 | |
|
C
|
S/T | 400 | 420 | 480 | |
|
D
|
H/T | 100 | 110 | 135 | |
|
E
|
REACH | 435 | 459 | 489 | |
|
F
|
STACK | 615 | 625 | 647 | |
|
G
|
FRONT ANGLE | 65º | 65º | 65º | |
|
I
|
REAR ANGLE | 76º | 76º | 76º | |
|
G
|
L/T | 205×60 TR | 205×60 TR | 205×60 TR | |
|
G
|
WB | 1215 | 1244 | 1284 |
| FIT GUIDE | |
| SMALL |
160 – 175
|
| MEDIUM |
175 – 185
|
| LARGE |
185 – 200
|
